Full Automatic Auto Plastic Pet HDPE Preform Filling Water Oil Food Bottle Can Jar Container Make Making Blow Bottle Blowing Mould Moulding Mold Molding Machine

Basic Info

Model NO.	MQ-32A
Raw Material	Pet
Making Method of Parison	Stretch Blow
Computerized	Computerized
Certification	CE, ISO9001:2008
Transport Package	Waterproof Film or Wooden Box
Specification	SGS TUV
Trademark	MQ
Origin	China
HS Code	8477300000
Production Capacity	5000pieces/Hour

Product Description

Machine specification:

ITEM	MQ-32A1	MQ-32A2	MQ-32A4	MQ-32A6
Cavity number	1	2	4	6
Container Volume	2L	2L	2L	2L
Mold Opening Stroke	118mm	118mm	118mm	118mm
Mold thickness	180mm	180mm	180mm	180mm
Stretching stroke	450mm	450mm	450mm	450mm
Theoretical output	1300 Bph(*)	2300 Bph(*)	3800 Bph(*)	5000 Bph(*)
Container diameter	50-105mm	50-105mm	50-105mm	50-105mm
Container height	50-360mm	50-360mm	50-360mm	50-360mm
Neck range size	28-38mm	28-38mm	28-38mm	28-38mm
Voltage/Frequency	Three-phase380V/50-60HZ
Total power	14Kw	24Kw	40Kw	62Kw
Use power	7Kw	12Kw	22Kw	30Kw
Working pressure	8bar	8bar	8bar	8bar
Blow pressure	30bar	30bar	30bar	30bar
Low Air Volume	1.0m³/min	1.6m³/min	2.0m³/min	2.6m³/min
High Air Volume	0.7m³/min	1.2m³/min	2.4m³/min	3.5m³/min
Water volume	16-25L/min	20-30L/min	20-30L/min	30-45L/min
Dimensions(L*W*H)	2.2*1.8*1.9m	3.2*1.8*1.9m	4.3*1.8*1.9m	5.6*1.8*1.9m
Weight	2000kg	2700kg	3900kg	4500kg
Pass rate	≥99.8%	≥99.8%	≥99.7%	≥99.7%

Machine Features:

1.Low labor and energy cost, high efficiency and profit, with automatic bottle embryo delivery process.2.The blow molding machine has automatic alarm, automatic fault detection and judgment function, easy and fast maintenance.3.Omron, Festo, Parkers are our accessories suppliers.4.Easy operation and stable performance with Mitsubishi or Siemens human-computer interface control program.5.Strong penetrability, even heating and energy saving with Philips infrared lamp.6.The blow molding machines are widely used in the production of mineral water bottles, edible oil bottles, food packaging bottles, daily chemical bottles, agricultural medicine bottles, and many other plastic container packaging fields.

Bottle Blowing Process:

Company Introduction:

Taizhou Maiqiang Machinery is located in Huangyan, Taizhou, Zhejiang Province, the hometown of mould in China. The company is manufacturing high speed automatic blow molding machine, automatic hollow blow molding machine, automatic high-capacity blow molding machine, semi-automatic blow molding machine and blow mold.The blow molding machines are widely used in the production of mineral water bottles, edible oil bottles, food packaging bottles, daily chemical bottles, agricultural medicine bottles, and many other plastic container packaging fields. Taizhou Maiqiang Machinery can provide a variety of bottle making equipments and very suitable technical solutions.Taizhou Maiqiang Machinery has professional design, production team, which provide a solid foundation for manufacturing excellent quality and performance blow molding machines. Our blow molding machines are exported to America, Europe, South korea, the Middle East, Southeast Asia, Central Asia, Africa and other countries and regions, they are well received and used by our customers.Taizhou Maiqiang Machinery will constantly improve the investment on research. With 20 years experience of manufacturing blow molding machine, we can provide users with stable, efficient, cost-saving bottle making equipments. Taizhou Maiqiang Machinery will offer efficient after-sales service and product solutions to be your worthy partner.Let's create a better tomorrow hand in hand!



Customer site view:

FAQ:

1.Are you a factory or trading company?
We are a factory, so the price is more favorable for you. Welcome to visit Taizhou Maiqiang Machinery !

2.What is your payment term?
30% down payment against order confirmation, 70% balance when the machines are ready. Upon receipt all your payment, we will delivery the goods at once.

3.Is this price a single machine price?
Yes, this price is the price of the machine, and the auxiliary machine is extra.

4.What is your delivery time?
All the machines will be produced according to the order. Usually in 20 working days, depends on your projects.

5.What about installing in customer factory?
After the machines arrive at your factory, we can arrange engineer to install the machines and train your workers.

6.What is the guarantee time?
We offer A one-year warranty and A lifetime after-sales service.
